Redis Settings - redis.config
ServerMemory usage limits
Default value
- 32bit System: 3GB
- 64bit System: 0
- 0: Unlimited use of operating system virtual memory (swap)
When memory is full, remove the key according to the uninstall policy.
It must be greater than the maximum memory usage for one Cache.
text
maxmemory 1gb| 1k | 1kb | 1m | 1mb | 1g | 1gb |
| 1,000 bytes | 1024 bytes | 1,000,000 bytes | 1024*1024 bytes | 1,000,000,000 bytes | 1012*1024*1024 bytes |
Remove Policy
LFU support starting with Redis 4.0
Use the DEL command to remove the key.
- DEL commands are executed in Main Thread.
text
maxmemory-policy volatile-lrunoeviction
Do not run the uninstall policy.An error occurs when a write operation is performed with full memory.
text
Servlet.service() for servlet [dispatcherServlet] in context with path [] threw exception [Request processing failed; nested exception is org.springframework.data.redis.RedisSystemException: Error in execution; nested exception is io.lettuce.core.RedisCommandExecutionException: OOM command not allowed when used memory > 'maxmemory'.] with root cause
io.lettuce.core.RedisCommandExecutionException: OOM command not allowed when used memory > 'maxmemory'.volatile
Execute an uninstall policy on the EXPIRE SET (the set of keys with Expire set).
If there is no object to be removed, it acts like noeviction.
| volatile-lru | The LRU algorithm removes the longest unreferenced key.(Recommended if you want to keep a single cache server, key permanently |
| volatile-lfu | The LFU algorithm removes the key with the least number of references. |
| volatile-random | Optionally remove the key.(Recommended if you want to keep a single cache server, key permanently |
| volatile-ttl | Remove the key with the least time-to-live (TTL) value (recommended if you use a different TTL for each key). |
allkeys
Enable uninstall policy for all keys
| allkeys-lru | The LRU algorithm removes the longest unreferenced key.(Recommended if only certain keys are used a lot in some cases) |
| allkeys-lfu | The LFU algorithm removes the key with the least number of references. |
| allkeys-random | Optionally remove the key.(Recommended if all keys are used uniformly) |
Number of candidates to be removed
Compare and eliminate candidate groups that meet the elimination policy.
text
maxmoery-samples 3Asynchronous Removal (Redis 4.0)
Settings to prevent Blocking from occurring when the purge policy is run, removing multiple keys at once
If yes is set, LazyFreeThread is performed in the background using the UNLINK command rather than the DEL command.
text
lazyfree-lazy-eviction yes- Use the UNLINK command to asynchronously remove the key when the uninstall policy is executed.
text
lazyfree-lazy-expire yes- Use the UNLINK command to delete expired keys.
text
lazyfree-lazy-server-del yes- Use UNLINK commands when executing SET or RENAME commands for keys that already exist.
text
lazyfree-lazy-user-del yes- The DEL command works internally as a UNLINK command.(Redis 6.0)
text
slave-lazy-flush yes- When replicating the entire data on the Master server to the Clone server, it is deleted with the FLUSHALL async command.Although synchronization speed is fast, additional memory may be required because new data is received without all existing data being deleted.
